Happymodel ExpressLRS ELRS EPW6 TCXO 2.4Ghz PWM 6 Channel Receiver

Name: Happymodel ExpressLRS ELRS EPW6 TCXO 2.4Ghz PWM 6 Channel Receiver
SKU: C1688-739208299098
Availability: InStock

$20.69

Shipping: Orders are processed within 3 business days. Delivery time depends on item size and shipping method. Shipping cost is calculated at checkout based on volumetric weight and destination. Shipping Policy

Returns: Eligible returns are accepted within 30 days after delivery. Non-defective returns may be subject to a USD 20 return label fee and a USD 20 restocking fee. Approved refunds are processed within 7 days after inspection. Return & Refund Policy

Brand notice: FPVBay is an independent seller. Brand names, product names, model names, and OEM references are used only for identification or compatibility purposes and do not imply affiliation or endorsement unless explicitly stated otherwise.

9971 in stock

Description

Key Selling Points

High performance ExpressLRS ELRS PWM 6 channel receiver for fixed-wing and RC car applications.
Features TCXO (Temperature Compensated Crystal Oscillator) for enhanced frequency stability and reliability.
Integrated 2.4Ghz communication for robust and long-range control with compatible ELRS radio transmitters.
Compact and lightweight design ensures easy installation and minimal impact on flight or vehicle performance.
Reliable signal reception for DIY RC projects and FPV fixed wing aircraft.

Technical Specifications

Brand	Happymodel
Protocol	ExpressLRS (ELRS)
Frequency	2.4Ghz
Channels	6 PWM
Oscillator	TCXO
Model	EPW6

FAQ Q&A

Q: What is the primary application for this Happymodel EPW6 receiver?

A: The Happymodel EPW6 receiver is primarily designed for fixed-wing aircraft and RC cars that utilize the ExpressLRS 2.4Ghz control link and require PWM output for servos and ESCs.

Q: Does this receiver require any special firmware flashing?

A: Yes, like other ExpressLRS receivers, it will likely require flashing with the appropriate ELRS firmware version to match your transmitter, typically done via Wi-Fi or passthrough.

Q: What is the benefit of having TCXO on this receiver?

A: TCXO (Temperature Compensated Crystal Oscillator) ensures more stable frequency performance across various temperature ranges, leading to improved signal reliability and link quality for the 2.4Ghz communication.
